Stone Solutions > StoneCUT® LINE

  • Full CNC Machine:4 or 5 axis

  • Saw Diameter (mm):350 to 800

  • Useful Cutting Area (mm): 3600 x 2000 / 4000 x 2200 / 4000 x 2500 / 4000 x 2800

  • Z Axis (mm): 500 to 900

  • Maximum Speed: 60m/min

  • Motor Power (HP): 23 / 27

  • Vision System for Detecting and Positioning

  • Tool Measuring and Slab Thickness Measuring Probe

  • Absolute Encoders

  • Centralized / Assisted Lubrication

  • Industry 4.0 Concept: Direct connection to office / smartphone/ tablet

  • Online Technical Support

  • CNC Cutting Line

  • Tilting Table for Loading Slabs

  • Conveyor Belt for Simultaneous Loading,

  • Cutting and Unloading Parts

  • Parts Validation Station With Barcode Printer

  • Robotized Loading and Unloading System

  • Parts Cleaning System

Options:

  • “Zero” Point on Workbench

  • Vacuum Manipulators (400 kg)

  • Laser for Manual Cutting Mode

  • Milling System ½” Gas

  • Additional High Rotation Drilling Motor

  • Automatic Saw Sharpening System

  • Software for Milling, Drilling, Engraving, Polishing,Profiles Frames and Parametric Figures
